Type SR SPEK Anchor made in china
| Price: | 1.0 USD |
| Payment Terms: | T/T,L/C,WU,Paypal,Money Gram |
| Place of Origin: | Liaoning, China (Mainland) |
|
|
| Add to My Favorites | |
| HiSupplier Escrow |
Product Detail
Type SR SPEK Anchors is the improved anchor with lower point of gravity based on hall anchor, Anchor fluke grounded easily, more stability, when SPEK
Type SR SPEK Anchor:
Type SR SPEK Anchors is the improved anchor with lower point of gravity based on hall anchor, Anchor fluke grounded easily, more stability, when SPEK Anchor haul up, anchor fluke will turn over against the hull, which would not make damage to ship hull.
SPEK Anchors Specification:
Material: Casting Steel
Weight: 80KGS to 20000KGS
Class Certificate: ABS, LR, BV, DNV, GL, NK, KR, IRS and CCS
| Nominal Weight (KG) | Size(mm) | |||
| A | B | F | D | |
| 210 | 810 | 500 | 340 | 690 |
| 240 | 810 | 500 | 340 | 690 |
| 300 | 980 | 550 | 390 | 760 |
| 360 | 970 | 600 | 412 | 828 |
| 420 | 970 | 600 | 412 | 828 |
| 450 | 970 | 600 | 412 | 828 |
| 480 | 1050 | 650 | 442 | 900 |
| 570 | 1050 | 650 | 442 | 900 |
| 610 | 1134 | 700 | 472 | 962 |
| 660 | 1134 | 700 | 472 | 962 |
| 750 | 1215 | 750 | 508 | 1032 |
| 780 | 1215 | 7850 | 519 | 1032 |
| 900 | 1296 | 800 | 547 | 1100 |
| 980 | 1296 | 800 | 547 | 1100 |
| 1020 | 1377 | 850 | 573 | 1170 |
| 1040 | 1458 | 900 | 591 | 1240 |
| 1100 | 1458 | 900 | 620 | 1240 |
| 1200 | 1539 | 950 | 640 | 1300 |
| 1300 | 1539 | 950 | 640 | 1300 |
| 1400 | 1539 | 950 | 671 | 1300 |
| 1500 | 1539 | 950 | 671 | 1300 |
| 1650 | 1620 | 1000 | 669 | 1378 |
| 1800 | 1700 | 1050 | 704 | 1454 |
| 1920 | 1700 | 1050 | 717 | 1454 |
| 2100 | 1700 | 1050 | 736 | 1454 |
| 2190 | 1700 | 1050 | 736 | 1454 |
| 2280 | 1782 | 1100 | 764 | 1454 |
| 2460 | 1863 | 1150 | 794 | 1584 |
| 2640 | 1863 | 1150 | 804 | 1584 |
| 2850 | 1944 | 1200 | 812 | 1650 |
| 3300 | 1944 | 1200 | 834 | 1650 |
| 3540 | 1944 | 1200 | 834 | 1650 |
| 3780 | 2187 | 1350 | 880 | 1850 |
| 4050 | 2187 | 1350 | 914 | 1850 |
| 4320 | 2268 | 1400 | 917 | 1926 |
| 4590 | 2268 | 1400 | 931 | 1926 |
| 4890 | 2268 | 1400 | 954 | 1926 |
| 5250 | 2349 | 1450 | 964 | 2000 |
| 5610 | 2349 | 1450 | 981 | 2000 |
| 5800 | 2430 | 1500 | 1006 | 2060 |
| 6000 | 2430 | 1500 | 1006 | 2060 |
| 6450 | 2430 | 1500 | 1023 | 2060 |
| 6900 | 2510 | 1550 | 1034 | 2138 |
| 7350 | 2510 | 1550 | 1062 | 2138 |
| 7800 | 2510 | 1550 | 1091 | 2138 |
| 8000 | 2510 | 1550 | 1091 | 2138 |
| 8300 | 2754 | 1700 | 1125 | 2332 |
| 8700 | 2754 | 1700 | 1166 | 2332 |
| 9300 | 2754 | 1700 | 1188 | 2332 |
| 9900 | 2754 | 1700 | 1188 | 2332 |
| 10500 | 2867 | 1770 | 1197 | 2440 |
| 11100 | 2867 | 1770 | 1212 | 2440 |
| 11700 | 2867 | 1770 | 1237 | 2440 |
| 12300 | 3094 | 1910 | 1260 | 2632 |
| 12900 | 3094 | 1910 | 1260 | 2632 |
| 13500 | 3094 | 1910 | 1316 | 2632 |
| 14700 | 3321 | 2050 | 1369 | 2824 |
| 16900 | 3434 | 2120 | 1415 | 2922 |
| 18800 | 3548 | 2190 | 1461 | 3018 |
| 20000 | 3548 | 2190 | 1493 | 3018 |
